Duratech One Piece Shelf Clip

Duratech One Piece Shelf Clip

  • Each intermediate shelf requires four sturdy & compact clips
  • Clips key snugly into post to hold shelves securely in place
  • Provides independent positioning of intermediate shelves on 1-1/2" centers
Angle Back Posts

Angle Back Posts
5004

Angles for single or end units. Slotted on 1-1/2" centers for easy shelf adjustment. Splice multiple posts for additional height.

H-Posts

H-Posts
5003

Used for high-density shelving requirements. Used with standard Hi-Tech shelving components side sway braces (5341). Order H-Posts front and back

Rivetwell - Angle Post

Angle Post (Standard-Duty)
APS ( HEIGHT 3' THROUGH 16' )

1-1/2" x 1-1/2" x 14 gauge cold rolled steel corner post uprights. Perfect for standard load situations.

Angle Post
APS ( HEIGHT 3' TO 16' )

Punched for self-adjustment on 1-1/2" centers

Beaded Front Post

Beaded Front Posts
5002

True flush construction. Slotted on 1-1/2" centers for easy shelf adjustment. Splice multiple posts for additional height.

Rivetwell - Angle Post

Angle Post (Heavy-Duty)
APH ( HEIGHT 6' THROUGH 16' )

Shall be 1-7/8" x 1-7/8" x 14 gauge cold rolled steel uprights. The choice when heavy-duty shelving is required. Perfect for multilevel installations.

Intermediate Shelf and Back of Shelf Clip

Intermediate Shelves

  • Compression clips hold the intermediate shelves securely while providing a quick and easy way to make adjustments
  • One-piece design, made from 13 gauge cold rolled steel and plated with zinc
T Post

T Post
TPS ( HEIGHT 3' THROUGH 16' )

Punched for self-adjustment on 1-1/2" centers

H-Post Splice

H-Post Splice
5010

Used to splice H-posts for added height requirements

Duratech Heavy-Duty Shelves

Duratech Heavy-Duty Shelves

  • Each intermediate shelf has lapped and welded corners
  • Available in three load capacity classes up to 48" wide spans and 36" depths
  • Exclusive triple bend side flanges for added strength
Double Rivet Angle Beam

Double Rivet Angle Beam
ABS ( Lengths 12" through 42" )

For left to right and front to back shelf support.

T-Posts

T-Posts
5006

Two back Posts welded together. For use when adjoining models are added to form a continuous row.

Side Sway Braces

Side Sway Braces
5341

For H-post only

Rivetwell - T-Post

T-Post (Standard-Duty)
TPS ( HEIGHT 3' THROUGH 16' )

3" x 1-7/8" x 14 gauge cold rolled steel. Punched for self-adjustment on 1-1/2" centers.

Tubular flange

Tubular flange

  • Tubular flange front and rear for greater strength
  • Available in three load capacity classes up to 48" wide spans and 36" depths
  • Top of shelf is punched to accept shelf dividers

Double Rivet Channel Beam
CBH ( LENGTHS 48" THROUGH 96" )

For left to right shelf support. Provides for a higher capacity than heavy-duty rivet angle beams

Post Slice Channels

Post Slice Channels
5009

A channel formed an internal splice. Used to splice beaded front posts, back posts, and T-posts for added height.

Cross Aisle Supports

Cross Aisle Supports
5910

For H-posts.

Rivetwell - T-Post

T-Post (Heavy-Duty)
TPH ( HEIGHT 3' THROUGH 16" )

3-3/4" x 1-7/8" x 14 gauge cold rolled steel intermediate uprights.

Triple flanged

Triple flanged

  • Triple flanged at all four sides for maximum rigidity, durability, and stability
  • Fully adjustable intermediate shelves for maximum versatility
Single Rivet Beam

Single Rivet Beam
SRB ( LENGTHS 12" THROUGH 48" ) SRBH ( LENGTHS 36" THROUGH 48" )

For use as left to right and front to back support.

Back Sway Braces

Back Sway Braces
5342

(2x) 1" x 11 ga. steel strips with safety edges bolted together at center to form an "X"

Side Panels
5091

Fabricated from 24 or 18 gauge cold rolled sheet steel, field bolted to front and back posts. Provide at all side locations for closed shelving sections.

Rivetwell - Single Rivet Shelf Beam

Single Rivet Shelf Beam (Standard-Duty)
SRB ( LENGTHS 12" THROUGH 48" )

This 14 gauge low profile standard intermediate level shelf beam is perfect when maximum clear opening is required between shelf levels.

Steel-grip locking nut

Steel-grip locking nut

  • Steel-grip locking nuts and bolts are used at each of the top and bottom corners
  • Top and bottom shelves are very tightly secured giving the needed integrity to the rest of the structure
Center Support

Center Support
CS ( LENGTHS 12" THROUGH 48" )

Bolts to double rivet angle or channel beams to add support to decking and stabilize beams. Supplied with nuts and bolts for fast assembly.

Side Sway Braces

Side Sway Braces
5344

(2x) 1" x 11 ga. steel strips with safety edges bolted together at center to form an "X"

Foot Plates

Foot Plates
5025

For H-post medium/light-duty

Rivetwell - Single Rivet Shelf Beam

Single Rivet Shelf Beam (Heavy-Duty)
SRBH ( LENGTHS 36" THROUGH 48" )

An 11 gauge heavy-duty version of our low profile intermediate shelf beam allowing maximum clear opening between shelf levels.

Duratech Angle Posts

Duratech Angle Posts

  • Roll formed into a unique angle shape for maximum strength
  • The long leg is punched on 1-1/2" centers to allow independent shelf adjustment
  • Four angle posts are used per section allowing units to be individually located, bolted side-by-side or bolted back-to-back
Double Row & Top Tie

Double Row & Top Tie
DRTT ( LENGTHS 9.25" THROUGH 48.25" )

Use to space back-to-back units and to top-tie rows across aisle for added stability.

Box Beam Shelves

Box Beam Shelves
5135 & 5138 & 5139

Medium-Duty, Heavy-Duty, or Extra-Heavy-Duty Roll-formed & triple-flanged. Top pierced to accept dividers.

Heavy-Duty Foot Plate for H-Post

Heavy-Duty Foot Plate
5015

Heavy-Duty Foot Plate for H-Posts

Rivetwell - Double Rivet Angle Beam

Double Rivet Angle Beam (Standard-Duty)
ABS ( Lengths 12" through 42" )

This 16 gauge shelf beam is essential for stability of standard units; therefore, is used on all four sides at the top and bottom levels. Can also be used front and back or on all four sides of intermediate levels to increase unit stability and load capacity.

Rivetwell - Double Rivet Angle Beam

Double Rivet Angle Beam (Heavy-Duty)
ABH ( lengths 48" through 96" )

Our heavy-duty double rivet angle beams provide additional unit rigidity for greater spans and higher shelf capacity.

Wall Tie

Wall Tie
WT09

Used to secure units to wall and provide space between wall and unit ( hardware not included to attached to wall )

Shelf Clip

Shelf Clip
5133

One-piece zinc plated compression clip fits snugly against side of posts to hold shelves in place. Four required per shelf.

Shim Plates

Shim Plates
5016

Fits under heavy-duty foot plate for leveling.

Shim Plates
5026

For H-post medium/light-duty footplate leveling.

Rivetwell - Double Rivet Channel Beam

Double Rivet Channel Beam
CBH ( LENGTHS 48" THROUGH 96" )

Maximized left-to-right shelf capacity is achieved using our 14 gauge double rivet channel beams in lieu of double rivet angle beams. These beams cannot be used at the bottom level.

Top and bottom shelves are punched at all four corners

Fixed top and bottom shelves

  • Top and bottom shelves are punched at all four corners so they can be secured with nuts & bolts to provide a rigid structure
  • Top and bottom shelves are fabricated from 18 gauge cold rolled steel and are triple flanged at all four sides
Foot Plate

Foot Plate
FPR100

For use in anchoring angle and T posts to floor.

Back Panels, 24 & 18 Gauge

Back Panels, 24 & 18 Gauge
5110

Two piece sections punched on 1" centers at vertical edges and center for mounting on back of posts and shelves.

Rivetwell - Center Support

Center Support
CS ( LENGTHS 12" THROUGH 48" )

 Used to provide additional shelf support front-to-back by bolting between double rivet beams at prepunched locations. Ideal for wider spans.

Post Splice

Post Splice
PS05

Used to extend post, attaches to outside of post. Order one per Angle Post, two per T-Post.

Back Panel Clips

Back Panel Clips
5120

Formed to fit bottom flange of standard shelf and tabbed to pick up holes in center of back panel. Holds back panel to shelf and prevents panel bowing.

Rivetwell - Double Rivet Z-Beam (Standard Duty)

Double Rivet Z-Beam (Standard Duty)
ZBS ( LENGTHS 12" THROUGH 60" )

Used in place of double rivet angle beams to add 1" additional clearance between shelf levels. Allows particle board decking to sit flush with beam. Protects decking edges. When used at bottom level of single rivet units, shelf clearance is increased by 1" at lower level. Standard Z beams are 14 gauge.

Tie Plate

Tie Plate
TP1

Used for structural integrity of T-Post and to join Angle Post units side by side to ensure proper row alignment.

Base Strips

Base Strips
5233

Shaped to fit directly between bottom shelf and floor. 2-15/16" high giving an overall base height of 3" including bottom of shelf.

Rivetwell - Double Rivet Z-Beam (Heavy Duty)

Double Rivet Z-Beam (Heavy Duty)
ZBH ( LENGTHS 48" THROUGH 72" )

Used in place of double rivet angle beams to add 1" additional clearance between shelf levels. Allows particle board decking to sit flush with beam. Protects decking edges. Heavy-Duty Z beams are 14 gauge

Bulk Rack Beams
5029 ( LENGTHS 48" THROUGH 96" )

14 gauge steel step beams with 10 gauge brackets

Bulk Rack Front to back supports
5029 ( LENGTHS 24" THROUGH 48" )

14 gauge front-to-back formed angle bracing supports

 Bulk Rack Welded Uprights

Bulk Rack Welded Uprights
5029 ( LENGTHS 24" THROUGH 48" )

Welded uprights consist of
14 gauge channel bracing welded to H-Post vertical members

Tire Rack Beam

Tire Rack Beam
TRB48 & TRB60

For left to right shelf support of tires. 9 degrees angle on supporting edge.

Side Panels
5091

Two-piece panels are bolted to standard Beaded, Angle, and T-Posts when solid sides are required.

Hanger Bar

Hanger Bar
HB ZBH ( LENGTHS 36" THROUGH 60" )

For hanging items between double rivet beams. One or more may be used per level.

Swinging Doors (With Locks)

Swinging Doors (With Locks)
5300

Reinforced door / frame attaches to beaded front posts and opens quietly to a full 150°. Chrome finished handle with built-in grooved key cylinder lock. Positive 3-point locking. Universal clips (Part No. 5315) are required to mount doors on beaded front posts.

DOGS Deck Over Grating Support

DOGS Deck Over Grating Support
DOGS ( LENGTHS 36" THROUGH 72" )

Provides secure support for grating when decking over entire installation.

Universal Clip To Mount Doors

Universal Clip To Mount Doors
5315

Available in sets of 6. One set required to mount swinging doors to beaded front posts.

Label Holders

Label Holders
5370

Pierced for attaching to front flange of shelves with top and bottom edges folded over to accommodate labels approximately 1" high.

Center Support for Z-Beams

Center Support for Z-Beams
ZC ( LENGTHS 24" THROUGH 48" )

Used with Z-Beams for front-to-back decking support. Fabricated of 11 gauge cold rolled steel.

Down Aisle Grating Support

Down Aisle Grating Support
DAGS ( LENGTHS 36" THROUGH 72" )

Attaches to unit front between rows to provide support for grating on 2-level Rivetwell installations

Beam Cleat
BC-L & BC-R

For hanging items between double rivet beams. One or more may be used per level.

Slotted Angle Cleat

Slotted Angle Cleat
SAC-L & SAC-R

For use where slotted angle pieces must be joined, such as special grating supports and top ties.

Welded End Panels

Welded End Panels
5092

Sections consisting of beaded front post, angle back post, and one-piece side panel.
Factory welded.

Welded End Panels H-post

Welded End Panels H-post
5095

Sections consisting of front H-post,  back H-post, and one-piece side panel.
Factory welded.

Double Rivet Z-Beam (standard or Heavy-Duty)

Double Rivet Z-Beam (standard or Heavy-Duty)
ZBH ( LENGTHS 48" THROUGH 72" )

For front to back and left to right. allows particle board decking to sit flush with top of beam.

Welded T-Panels

Welded T-Panels
5094

Sections consisting of beaded front post, back T-Post, and one-piece side panel.
Factory welded.

Bin Fronts

Bin Fronts
5220

Offset type with bead at top and triple flange at bottom to telescope over shelf flange.

Center Support for Z-Beams

Center Support for Z-Beams
ZCS ( LENGTHS 24" THROUGH 48" )

Use with Z-beams for additional decking support front to back.

Full Dividers

Full Dividers
5240

Flanged at top rear and bottom, or just bottom to form shelf dividers.

Partial Dividers
5250

Flanged at top rear and bottom, or just bottom to form shelf dividers.

Coat Rod Support Beam

Coat Rod Support Beam
ABH ( LENGTHS 18" THROUGH 48" )

For supporting Rivetwell coat rods

Nylon Buttons

Nylon Buttons
5260

Available in sets of 6. One set required to mount swinging doors to beaded front posts.

RCR  Rivetwell Coat Rod

RCR Rivetwell Coat Rod
RCR ( LENGTHS 36" THROUGH 72" )

For use with coat rods and support beams

Cross Aisle Supports
CAS

For beaded posts.

Cross Aisle Supports H-Post

Cross Aisle Supports H-Post
5910

For beaded posts.

Wire Deck

Wire Deck

Rivetwell wire decking is powdercoat gray

Particle Board Decking

Particle Board Decking

Smooth high-quality particleboard decking for Rivetwell units

Cross Aisle Support Brackets

Cross Aisle Support Brackets
5914

Brackets for cross aisle supports.

EZ-Deck Steel Decking

EZ-Deck Steel Decking

EZ-deck steel decking fro Rivetwell shelving units

Down Aisle Supports

Down Aisle Supports
5905

For beaded posts and H-posts.

Down Aisle Support Brackets
5912

For beaded posts and H-posts.

Combination Clips

Combination Clips
5027

Connection Strips

Connection Strips
5114

Row ends.

Connection Strips

Connection Strips
5115

Intermediate.

 Foot Plates

Foot Plates
5050

For beaded, angle, and T-posts.

Shim Plates
5033

Medium/light-duty or heavy-duty

Shim Plates
5026

Medium/light-duty or heavy-duty

Foot Plate Heavy-duty

Foot Plate Heavy-duty
5032

Extra-heavy-duty for beaded, angle and T-posts
